Optimised specifically for the new MF 5M, the rear linkage boasts generous lift capacity from 4.3T to 5.2T, with Electronic Linkage Control ensuring precise draft functions and optimal traction.

Fully adjustable lift rods and heavy-duty stabilisers provide plenty of adjustment for the perfect attachment and setting for a wide range of mounted and semi-mounted implements.

For added productivity, a 2.5T front linkage is available. This option, equipped with suspension for improved comfort, has three operating modes: fixed, float, or transport.

Useful standard features include Active Transport Control, which automatically absorbs shocks on the road, as well as external lift/lower controls, located on the right and left-hand fenders.

This range features an open-centre hydraulic system powered by two gear pumps, delivering 32 litres/min for internal services and 58 litres/min for auxiliary functions.

At the press of a button, the MF 5M Series hydraulics can deliver 100 litres/min oil flow at 2220 rpm, making the higher flowrate availabe to provide extra speed and power for loader operations.

The oil flow is also available through the two standard auxiliary spool valves to power implement hydraulic functions, even while operating the steering. An optional factory-fitted third spool valve is available to power more complex implements.

The MF 5M series is equipped with a two-speed 540/540 Eco/1000rpm PTO as standard. A 21-spline shaft is an option with the 1000rpm PTO.

Control is through a modern independent PTO clutch, electro-hydraulically engaged, regulating the engagement to protect the implement driveline. Maximum reliability is combined with ease of use, with control by a three-position rocker switch

The heavy-duty, structural axle casting design contains inboard reduction units, which employ epicyclic gears for the final speed reduction.

An unladen weight of 4T allows road transport with peace of mind, carrying up to 4,5T or towing up to 28T at a speed of 40 km/h, with simple operation including automatic gear shifting thanks to our famous Dyna-4 transmission

Specially designed cutaways in the chassis and bonnet help deliver a turning radius of 4.65m (until model MF 5M.115), making it easier to operate in confined areas and buildings.

Fully compatible from the factory with MF FLX & MF FL Series loaders, it offers excellent manoeuvrability with a choice of mechanical or electronic joystick, to suit your requirements.

The Visio Roof option provides perfect visibility when stacking bales or loading trailers. The glass panel includes a sun blind and has a level of sun protection. The roof, fully FOPS (Falling Object Protection) certified, complete safety for the operator

With a wide range of tyre sizes available (up to 600/65 R38), you can adapt your MF 5M to meet different needs in terms of height, stability, or traction. If you can't find the factory setup you want, our MF By You customisation offer can always help!

This design pays tribute to the brand’s heritage, incorporating an interpretation of the iconic MF grey sabre stripe on the side of the bonnet, and the grey cab, both dating back to the MF 100 series.

The numbering follows the same format as the other MF tractor series. 5 represents the chassis size; M indicates the specification level (Medium) and the three final figures emphasise the power that, across the new 6-model series, goes from 95 to 145 HP.

Wide opening doors, and large even better integrated steps offer easy, offer easy access to the MF 5M cab.

Thanks to the slim bonnet, the discreet exhaust pipe, the wide glass area and the LED lighting package, you will enjoy extra productivity and safety during long working days.

​Quality seats and optional cab suspension will further increase the pleasure of driving this tractor, which was developed to be efficient but also enjoyable for all your farming activities.

A completely flat floor creates the most accessible and spacious operator environment in this sector of the market, with a pillar to pillar width of 1,300mm.

​The joysticks, the levers and all other controls are designed and located to make daily operations as easy  and ergonomic as possible, and to ensure your comfort.

​For excellent comfort and ergonomics, you can choose between the accessible, simple and mechanical joystick or the advanced, best-in-class electronic one, following your requirements.

Electronic multifunction joystick allows operators to control loader functions as well as the transmission; travel direction; speedshift; engine memo; 3rd and 4th electric functions​.

The dashboard displays engine and PTO speeds, service intervals, fuel consumption, distance travelled, area worked, oil temperature, tractor hours, engine speed memory and service information. You can also adjust the Comfort Control to fit your activity.

​Uprated, optional air conditioning system with greatly increased air flow and distribution around the operator.

The MF 5M can feature the intuitive Fieldstar 5, 9-inch touchscreen, integrating the entire MF Smart Farming package, while offering an easy-to-use experience.

The MF 5M provides guidance with MF Guide accuracy ranging from sub-metric to centimetric levels, enhancing driving comfort, saving inputs and costs, and maximising return on investment.

The optional MF Connect telemetry feature provides real-time machine management information enabling predictive maintenance and maximum uptime.

Link the implement directly to the tractor controls for greater comfort and working efficiency.

MF Rate Control allows automatic variation of seeding and application rates in response to instructions on a prescription map

Automatically switch up to 96 different sections on and off to prevent overlaps and misses, and to save fuel with MF Section Control.

MF TaskDoc™ records data quickly and easily to create field records, make job reports and keep accurate records of inputs.

Offers a courtesy fleet to ensure uninterrupted work. Whether your MF products need servicing or repairs, temporary replacements keep your farm operations running smoothly.

Offers customisation options from our Beauvais centre, allowing you to tailor your tractor to meet your specific needs.

Ensures peace of mind with comprehensive warranty package covering your MF machines and ensuring they perform reliably throughout their lifecycle.

Offers genuine AGCO Parts designed for optimal efficiency and durability, ensuring your machine operates at peak performance.

Provides dedicated dealer and technician support, along with proactive alert services to maximise uptime.
