A Pure Concentration of Power

Introducing the MF 6700 S Stage V

Welcome to the “S Effect” from Massey Ferguson!

The New MF 6700 S blends all the benefits of a four-cylinder machine with the pulling, pushing and lifting power to match a comparable six-cylinder tractor.

The result is a tractor that combines concentrated energy and power density, suiting perfectly the needs of those seeking a machine with compact dimensions, yet with the carrying and power capacity at each end to lift and drive the very latest implements.

Key Benefits

Virtual Reality
Image Gallery

Technology & Innovation

The super powered tractor with concentrated power and energy.

AGCO Power Engine

AGCO POWER 4.9 Litre 4 Cylinder Engine.

Power Control

The Power Control lever provides convenient three-in-one, straightforward operation. Operators can shuttle between forward/reverse, shift Dynashift speeds and ranges and select neutral, leaving the right hand free.

All-in-One Stage V Engines

These comply with the strict Stage V emission regulations using Massey Ferguson’s award-winning ‘All-in-One’ system, which now includes a straightforward ‘soot catalyst’.

Dyna-VT

With the continuously-variable Dyna-VT transmission, Massey Ferguson engineers have developed a system of power transfer that sets a new benchmark for ease-of-use and precision.

Dyna-6

Delivering class-leading dynamic performance and reliability, the semi-powershift transmission consists of six Dynashift ratios, optimally stepped in four ranges and changed without recourse to the clutch pedal.

Engine Power Management - 20 HP Boost

These tractors have the considerable benefit of Engine Power Management (EPM), which gives the capability of up to a 20 hp-plus power boost, plus extra torque, whenever that bit extra is needed.

The cabs on the MF 6700 S provide an environment designed specifically to counter stress and fatigue by providing unparalleled comfort, simplicity and visibility.

Essential Cab

This may be the base specification but it’s anything but basic. It provides all the key qualities you would expect from a Massey Ferguson tractor – simplicity, logic and versatility – but without excessive sophistication.

Exclusive Cab

This level, with its more advanced features, aims to cater for more intensive, larger-scale operations seeking cost-effective benefits for the business.

Efficient Cab

Dedicated to delivering increased productivity thanks to key features, the Efficient package will enable the operator to work faster, to a higher standard and with more accuracy.

Right-Hand Pillar - Essential Cab

The right-hand pillar houses those switches that are used less frequently, such working light controls and the ignition key.

Essential Panoramic Cab

Clear, unobstructed visibility to the right-hand side allows safe and efficient operation of side-mounted equipment. The wide, one-piece screen is extremely tough and protects the operator from any flying debris.

Right-Hand T-Handle

Simply move the T-shaped transmission control lever forwards or backwards to change up or down through the four Dynashift ratios. To change range, simply press the range selection button as you move the lever.

12 LED Lights

Outside, up to 12 LED lights turn night into day with outstanding brilliance and very low energy consumption The LED package is also visibly striking during daylight hours, as their design enhances the tractor‘s external appearance.

Quadlink Suspension System

The Quadlink system, which can be switched on and off, uses hydraulic accumulators acting on the front axle to dampen ride over rough roads and fields, and improve comfort and safety on transport applications.

The MF 6700 S has been designed to offer immense (and upgraded) capabilities that were previously the domain of six-cylinder tractors, to easily handle heavy-duty applications with outstanding lift and drive capabilities for the very latest implements.

Turning Circle

MF 6700 S tractors can turn in a circle just 9.5m in diameter. That means faster headland turns, quicker loader work and a more productive man and machine.

New 1 85m Diameter Rear Tyre

New standards of ground traction are set by the new 1.85m diameter rear tyre, available on all Dyna-6 models as an option. Ground clearance is enhanced and soil compaction reduced.

Spool Valves

Between two and four electro-hydraulic valves are fitted as standard and up to five rear spool valves may be available if required.

Rear Linkage Capacity - 9600 kg

The rear linkage offers a capacity that can reach 9,600 kg. Rear couplers are equipped with an hydraulic decompression system for easy uncoupling of implements and a total of up to five spool valves are available.

Integrated Front Linkage System

A heavy duty Integrated Front Linkage System (IFLS) is available as an option and is designed to match the front suspension.

Accurate Draft Control

Massey Ferguson’s digital ELC system gives the highest standards of draft control with more accurate depth settings and better ground contour following.

Automatic Stabiliser Installation

Automatic stabiliser installation has also been improved with a shorter chain for the simplest installation. A one way stabiliser each side offers extra reliability.

The on and off-board technology solutions incorporated into the MF 6700 S Series are a clear indication of the pace of progress and innovation setting by Massey Ferguson. Information is power when it comes to get the job done more efficiently and more productively. This is the reason why Massey Ferguson delivers straightforward and dependable technology solutions resulting in unbeatable ease of use, improved productivity and profitability through higher yields, lower inputs costs and greater profits.

Datatronic 5

Available as an option on Efficient and Exclusive models, Datatronic 5 gathers and stores data on both tractor and precision farming setting. In addition, the terminal can be used to control MF Auto Guide, ISOBUS and cameras.

Fieldstar 5

The new Fieldstar 5 terminal is designed in order to create a more intuitive Precision Farming experience, providing a system that delivers a straightforward an easy to use experience, improving efficiency, productivity and profitability.

ISOBUS

Reduce the number of additional screens – and eliminate the need for another joystick – with ISOBUS compatibility, a feature integral to the Datatronic specification.

MF Task Doc

The MF Task Doc system has a real place in the future of agriculture, helping farmers to become more productive through the knowledge brought by putting precision-measured data at the business owner’s fingertips.

MF Guide

MF Guide is MF’s full featured, hands free steering system, available on new tractors or as an after-market installation. It is capable of delivering sub-metre, decimetre and centimetre accuracy, increasing the efficiency of your farming.

AgControl

With the fully automatic Section Control for ISOBUS implements, operators can apply seeds, fertilizer or pesticides without overlapping. This prevents double treatment and areas worked outside of the field edges.

MF Connect

MF Connect service enables you — and your dealer — to coordinate, optimize and seamlessly connect your fleet, to better manage maintenance and remotely monitor equipment in the field.

Available Models

Model	Max Power (hp)	Engine	Transmission	Max Torque (Nm)*	Lift Capacity (kg)
MF 6713 S	135	All-in-One Stage V	Dyna-6, Dyna-VT	648	9,600
MF 6714 S	145	All-in-One Stage V	Dyna-6, Dyna-VT	691	9,600
MF 6715 S	155	All-in-One Stage V	Dyna-6, Dyna-VT	745	9,600
MF 6716 S	165	All-in-One Stage V	Dyna-6, Dyna-VT	790	9,600
MF 6718 S	180	All-in-One Stage V	Dyna-6, Dyna-VT	845	9,600
* @ 1,500 rpm with EPM
