MF 5700

Products

Born Adaptable

Introducing the MF 5700 Global Series

The MF 5700, Designed for Versatility | 92 HP - 110 HP

The MF 5700 provides another example of the benefits of a ground-up redesign that is common to all of our Global Tractor Series. While it shares some features with the MF 4700 the MF 5700 medium horsepower tractor is remarkable for the variety of build specifications, options and accessories which make it supremely able to be tailored to your farming needs.

Operator comfort and ease rates high as a priority with the MF 5700 with an air seat and ergonomic controls and the opinion of comfort control to opt for smooth or quick shifting between forward and back. See our offers or get a quote today.

Our Global Series Tractor models include the MF 4700, MF 5700 and MF 6700. MF Global Series tractors are purpose built in the latest state-of-the-art facilities, combining the very best of today’s technologies with comfort, simplicity, reliability, and quality. No other range on the market today offers such an array of build specifications and accessories, all designed to help tailor your machine exactly the way you need it for your farming operation.

Current Offers & Promotions

MF 5700 Dyna 4 Global Series MHP Tractors I 100-110 HP

2.99% P.A.^ Finance Available

Offer valid to November 30, 2024, while stocks last.

MF 5700 Series Utility Tractors | 92-102 HP

2.99% P.A.^ Finance Available

Offer valid to November 30, 2024, while stocks last.

Key Benefits

Video
Image Gallery

Technology & Innovation

The muscle to tackle any task.

Comfort Control

Smooth or quick shuttling – you choose by simply adjusting the Comfort Control to suit the job – slow and smooth or fast and efficient.

Creeper Speeds Option

Close control in specialist low-speed tasks is assured with additional creeper gears, enabling forward speeds as low as 100m/hr to be achieved.

Super Creeper Option

A Super Creeper option is also available when the slowest speeds, down to 140m/hr, are required for the job in hand.

Driveline

Every component of the chassis has been designed from a blank sheet of paper to boast immense strength, a major factor in an agricultural tractor’s overall performance. This modern design provides versatility, power, durability and outstanding capability.

All-New Synchromesh Transmission - AME Models

An all-new 12 forward x 12 reverse synchromesh transmission with the option of either mechanical or full power shuttle and 30km/hr maximum transport speed. Featuring slick gear changes and eight gears in the typical field working range from 4-12km/hr.

All-New Synchronised Transmission

All-new synchronised transmission which provides a total of twelve forward and twelve reverse speeds courtesy of two ranges.

Power Control

The Power Control lever provides convenient three-in-one, straightforward operation. Operators can shuttle between forward/reverse, shift Dynashift speeds and ranges and select neutral, leaving the right hand free.

A tractor that has been designed with simplicity of operation at its heart doesn’t have to have a basic operator environment. Designed from the outset with an emphasis on comfort and ease of use, the MF 5700 Series tractors make hard work a pleasure.

Neatly Positioned Gear Levers

The right speed for each job is easily selected using gear levers that are within easy reach, yet positioned neatly to hand of the driver, ensuring an unimpeded passage when mounting/dismounting.

360 Visibility

The great view over the bonnet is maintained thanks to the compact ‘All-in-One’ SCR system, providing 360° visibility for optimum comfort and safety at work.

Grab Rails

Grab rails mounted outside the operator station provide easy access to the footsteps, mounted directly to the machine.

The key to reliable, heavy-duty machinery is to choose a tractor that meets the requirements of today’s modern implements and utilizes them to their full potential within a wide range of agricultural applications. There is no limit to the range of powered equipment that can be put to work behind the MF 5700 Series tractors.

4WD Front Axle

Specified with a limited slip differential, the front axle boosts traction and stability with maximum simplicity and minimal maintenance.

Direct Drive PTO

Each model is fitted with a 35mm six-spline PTO shaft providing 540, 540E or 1000 PTO speeds and protected by an independent PTO clutch (IPTO).

2WD Front Axle

Giving excellent manoeuvrability and adjustable track width.

55 Degree Steering Angle

Manoeuvrability is maximised by the front axles 55° steering angle.

Combined Flow System

For those requiring extra flow – to boost loader performance – the MF 5700 series can be specified with a 98 litre/min combined flow system.

Open-Centre Hydraulic System

A simple open-centre hydraulic system, powered by two gear pumps, the 32 litres/min pump provides all the internal services, whist the 58 litres/min pump allows the electronically-controlled rear linkage to lift 4,300kg.

Spool Valves

Two spool valves are fitted as standard and with the option of up to four, modern complex equipment can be operated with ease.

100 Litres Combined Flow

At the press of a button the hydraulics can deliver 100 litres/min oil flow, making the higher flowrate available to provide extra speed and power for loader operations.

IPTO

Control is via a modern independent PTO (IPTO) clutch, which is electro-hydraulically engaged and ‘eases’ the engagement, to protect the driveline by gradually taking up the drive.

Electronic Linkage Control - ELC

The industry leading ELC is provided as standard. The system provides precise and responsive control of linkage functions ensuring accurate management of working depth for soil engaging implements plus working height for other implements.

Available Models

Model	Max Power (hp)	Engine	Transmission	Max Torque (Nm)*	Lift Capacity (kg)
MF 5709	92	AGCO Power 4.4L, 4 cylinders	Synchronised 12 x 12 Power Shuttle	380	4,300
MF 5710	102	AGCO Power 4.4L, 4 cylinders	Synchronised 12 x 12 Power Shuttle	410	4,300
MF 5710 D	100	AGCO Power 4.4L, 4 cylinders	16 x 16 Dyna-4 PowerShift	410	3,497
MF 5711 D	110	AGCO Power 4.4L, 4 cylinders	16 x 16 Dyna-4 PowerShift	410	3,497
* @ 1,450 RPM
