The MCS provides a massive separation area to remove as much grain as possible before it reaches the walkers. The MCS has the ability to rotate the concave over the top of the rotary separator when it is not required.

The grain tanks have a high capacity (9000 litres) while the unloading rate of 105 l/sec is one of the highest in the class.

The 6 row straw chopper is specifically designed to give chopping and spreading performance suitable for farmers using reduced tillage operations. The knives are serrated to give a clean fine chop and reduce the power required.

MF can offer an optional Sectional concave which is designed to harvest a multitude of crops. The conversion time when moving from small grain to large seeded crops such as Soya, Maize and Sunflower can be completed in minutes rather than hours.

The long straw walkers feature four steps with ‘active walls’. The 21 cm high, vertical sections of the walker steps are made up of permeable grids. The front steps of the straw walkers are reinforced for maize.

The threshing drum has added weight in the form of ballast bars to increase the inertia behind the rasp bars as they thresh the heads. This reduces load on the drives, power requirement and fuel consumption.

The concave has differentiated wire spacing, and the rear section of the concave has half as many wires as the front section. This principle provides the optimum balance between high threshing capacity and good grain flow through the concave.

The sieve profile is the key to shaker shoe performance. The high performance sieves are specially designed with vertical tags which improve the sample and allow you to open the sieves wider for greater throughput.

A special Rice cylinder / concave version can be ordered with unique peg and tooth design, specifically for separation in tough conditions.

Our rubber tracks option has positive transmission, auto tensioning and much lower compaction in difficult conditions. The integrated final drives are specially developed for high loads.

Perfectly in view and reach is the TechTouch terminal, providing all the relevant performance information and settings for the combine, touch screen controls with clear definition are easy to use and adjust.

Night working package includes H9 high intensity lights for all-round excellent visibility late into the evening.

The membrane keypad is located directly on the right side of the armrest and is used to operate the principle combine functions. The soft, raised keys lead directly to the individual menus on the TechTouch terminal.

Using the latest technology the Auto-Guide xls option can steer you through to higher performance optimising the field layout - easily set from the terminal Auto-Guide xls can offer accuracy down to 5cm or you can use an RTK signal if required.

The new control interface for the operator falls naturally to hand - the PowerGrip Multifunction lever sits on top of the armrest which houses all the switches for the commonly used controls.

The right-hand armrest is the central operating unit where the key engagement switches sit with the throttle control. Designed with a large soft pad to cushion the arm during a long day allows for maximum comfort.

We can promise you that your AGCO Power engine has been designed to match the latest emission regulations using SCR technology meaning that actually it has one of the most advanced designs on the market.

Fuelling is designed to give a flat torque curve, required to give a constant delivery under load despite the conditions. This coupled with the low friction drives will give you incredibly low fuel consumption per tonne and excellent fuel economy.

Easy refueling - both tanks are located next to each other for easy access.

Ladder rail makes inspection easy and safe.

One piece panels with lights allow for quick inspection access with lights for night work.

Safe and simple access for radiator cleaning.
